TCI DC 70W 24V K3 70W 24V 122180
Features:
- Electronic AC/DC driver with output voltage, designed for standard-compliant lighting installations.
- Independent IP20 driver for indoor use.
- Class II protection against electric shock from direct or indirect contact (DC 70W K3).
- Active power factor corrector.
- Input and output terminals on the same side (wire cross-section up to 1.5 mm²/AWG15).
- Terminal screws on primary and secondary circuits for wire diameters: min. 3 mm - max. 8 mm (DC 70W K3).
- Power: 70W
- Voltage: 24V
- Power Frequency: 50 – 60 Hz
- Power Factor (λ): 95 0.95
- Efficiency: > 92%
Protection:
- against short circuits;
- against mains voltage surges;
- against overloads.
Certifications:
EN 55015, EN 61000-3-2, EN 61000-3-2, EN 61347-1, EN 61347-2-13, EN 61547, EN 62384
