Merrytek DALI MSA055 Motion Sensor

Name: Merrytek DALI MSA055 Motion Sensor
Brand: merrytek
SKU: MSA055
Price: 195.89 PLN
Availability: InStock
Rating: 5 (1 reviews)

zł195.89

Tax included

Quantity

0 review(s)

Security policy

Delivery rules

Return Policy

Description
Product Details
Comments

Merrytek DALI MSA055 Motion Sensor

Motion sensor: Powered by DALI Bus

Parameters:

Rated current: 13±1mA
Communication mode: DALI Bus
Operating frequency: 5.8GHz±75MHz, ISM band
Radiation power: Max. 1mW
Detection area: 100% / 75% / 50% / 25%
Backup time: 1s-30min, settable via DALI master (default: 5s)
Ambient light level measurement range: 5-1000lux (mounting height: 3m, measuring the lux level reflected from the ground directly below the product)
Detection range (100% sensitivity, radius): 3m
Mounting height: 2.5-4.0m, typical: 3m
Beam angle 3D: 80° (XZ)
3D beam angle: 96° (YZ)
Operating temperature: 0 - 50℃

Reference MSA055

In stock 5 Items

No customer reviews for the moment.
