The professional DAMIK KON16 hermetic connector is a reliable solution for safely connecting, branching, and extending electrical cables in areas exposed to water, dust, and harsh weather conditions.
With an IP68 rating, it guarantees full protection even during prolonged immersion, making it an ideal choice for outdoor, garden, and industrial installations.
Key Features:
IP68 waterproof – complete protection against water and dust
Rated current: up to 17.5 A
Rated voltage: up to 450 V AC
Wire range: 0.5 – 1.5 mm² (cable diameter Ø 3–6.5 mm or Ø 5–9 mm)
Connection type: screw, solderless
Material: PA66 / PC resistant to UV, fire, impact, and chemicals
Operating temperature range: -40°C to +105°C (intermittent up to +120°C)
Flammability class: V0
Dimensions: 6.5 × 2 cm
Certificates: TUV, CE, CB, UKCA, NSW, ETL, RoHS
Applications:
The DAMIK KON16 connector is used in:
LED lighting installations (exterior and garden)
Gate and water pump automation
CCTV and signaling systems
energy and industrial installations
maritime industry and areas with high humidity
Why choose the DAMIK KON16?
Hermetic IP68 design ensures complete protection against water and dust
Durable materials ensure a reliable and long-lasting connection
Easy screw installation – no soldering required
Ideal for outdoor, industrial, and garden applications
KON16 3P
